Cordless Drills · Comparison

The DeWalt 20V MAX XR DCD800 Drill/Driver meets
the Ryobi ONE+ 18V PCL206 Drill/Driver

HGTV's best overall after 500-plus holes and 2,000-plus screws, beating a Milwaukee M18 that testers said would otherwise have won. We tested it head-to-head against the Ryobi ONE+ 18V PCL206 Drill/Driver across 5 key dimensions.

DeWalt 20V MAX XR DCD800 brushless drill/driver, three-quarter front view with its metal ratcheting chuck, 5Ah XR battery attached and belt hook, on white
BEST

DeWalt 20V MAX XR DCD800 Drill/Driver

“HGTV's best overall after 500-plus holes and 2,000-plus screws, beating a Milwaukee M18 that testers said would otherwise have won”

Our Score
90.1 / 100
Ryobi ONE+ PCL206 18V 1/2 in. drill/driver kit on white: drill with the 18V 1.5Ah ONE+ battery attached, next to the ONE+ charger
VALUE

Ryobi ONE+ 18V PCL206 Drill/Driver

“Reviewed's best value and Bob Vila's best for home use, with 515 in-lbs of torque and a 24-position clutch for under $90”

$89MSRP
Our Score
72.4 / 100
01

Head-to-Head Breakdown

Power
35% of score +
DeWalt
92
Ryobi
66
DeWalt 20V MAX XR DCD800 Drill/Driver

HGTV's Kamron Sanders called it incredibly powerful and said nothing in testing slowed it down. A 1.7Ah PowerStack battery drilled 54 holes per charge. It tops out at 2,000 rpm, though DeWalt rates it in unit watts out rather than publishing an in-lb figure.

Ryobi ONE+ 18V PCL206 Drill/Driver

Bob Vila's testers found its performance nearly identical to brushless drills of the same size, with 515 in-lbs and up to 1,750 rpm. In Outdoor Life's test it drove a lag bolt only 1.5 in deep, half what the Milwaukee M18 FUEL managed.

Build
20% of score +
DeWalt
90
Ryobi
68
DeWalt 20V MAX XR DCD800 Drill/Driver

A metal ratcheting chuck and a brushless motor, backed by DeWalt's 3-year limited warranty plus a year of free service. HGTV's only build complaint was the kit bag.

Ryobi ONE+ 18V PCL206 Drill/Driver

BestReviews praised its durability in drop tests, but Bob Vila flagged the brushed motor and plastic chuck, and Outdoor Life felt it might be prone to issues after hard use. Ryobi backs it with a 3-year warranty.

Ergonomics
15% of score +
DeWalt
86
Ryobi
74
DeWalt 20V MAX XR DCD800 Drill/Driver

HGTV said it feels great in the hand. It weighs 3.2 lb bare with a 6.4 in head, a bit heavier and longer than the Milwaukee M18 3601.

Ryobi ONE+ 18V PCL206 Drill/Driver

Light at 2.6 lb, though Reviewed found some controls awkward and Bob Vila's under-$100 test called it one of the heavier drills once the battery is in.

Precision
15% of score +
DeWalt
88
Ryobi
80
DeWalt 20V MAX XR DCD800 Drill/Driver

Fifteen clutch settings, two speeds (0-650 and 0-2,000 rpm) and a 3-mode LED up to 70 lumens with a spotlight setting for precise work.

Ryobi ONE+ 18V PCL206 Drill/Driver

A 24-position clutch and a two-speed gearbox (0-450 and 0-1,750 rpm), tied with the FLEX for the most clutch steps here. Outdoor Life called its LED the brightest and most useful in its test.

Trust
15% of score +
DeWalt
92
Ryobi
84
DeWalt 20V MAX XR DCD800 Drill/Driver

DeWalt's XR line is a pro standard. HGTV ranked it first of 10 drills tested, and Family Handyman picked it for advanced DIYers and pros.

Ryobi ONE+ 18V PCL206 Drill/Driver

Five of our sources tested or recommend this ONE+ drill, including Reviewed's best value and Bob Vila's best for home use. The ONE+ battery fits Ryobi's huge 18V tool line.

02

Strengths & Weaknesses

DeWalt 20V MAX XR DCD800 Drill/Driver

+ Strengths
  • HGTV's best overall after drilling 500-plus holes and driving 2,000-plus screws
  • Drilled 54 holes on one charge of a small 1.7Ah PowerStack battery
  • Metal ratcheting chuck and a 70-lumen, 3-mode LED
− Weaknesses
  • Family Handyman notes it costs about twice as much as DeWalt's basic 20V MAX drills
  • DeWalt doesn't publish an in-lb torque figure
  • At 3.2 lb bare it's heavier than the Milwaukee M18 3601
Key flaw: It isn't cheap.

Ryobi ONE+ 18V PCL206 Drill/Driver

+ Strengths
  • Reviewed's best value, Bob Vila's best for home use and BestReviews' best budget brand
  • 515 in-lbs of torque and a 24-position clutch, which Bob Vila found close to brushless drills of its size
  • The battery fits the whole Ryobi ONE+ lineup
− Weaknesses
  • Brushed motor and a plastic chuck
  • Outdoor Life found it drove a lag bolt only 1.5 in deep, the weakest result in its test
  • Sold through Home Depot, not Amazon
Key flaw: It has a brushed motor and a plastic chuck, which Bob Vila flagged, and it runs out of muscle on big jobs.
03

The Verdict

Our Bottom Line

HGTV's Kamron Sanders put 10 drills through more than 500 holes and 2,000 screws, and the DeWalt DCD800 came out on top. He called it incredibly powerful and said nothing he threw at it slowed it down. Even on a small 1.7Ah PowerStack battery it drilled 54 holes before needing a charge. The runner-up was Milwaukee's M18 3601, which he said would have topped the list if not for the DeWalt.

BEST
DeWalt 20V MAX XR DCD800 Drill/Driver
DeWalt 20V MAX XR DCD800 brushless drill/driver, three-quarter front view with its metal ratcheting chuck, 5Ah XR battery attached and belt hook, on white

HGTV's Kamron Sanders put 10 drills through more than 500 holes and 2,000 screws, and the DeWalt DCD800 came out on top. He called it incredibly powerful and said nothing he threw at it slowed it down. Even on a small 1.7Ah PowerStack battery it drilled 54 holes before needing a charge. The runner-up was Milwaukee's M18 3601, which he said would have topped the list if not for the DeWalt.

Best for:
  • Serious DIYers building decks, sheds and furniture
  • Tradespeople who need a compact drill/driver for daily use
  • Anyone already on DeWalt 20V MAX batteries
  • People who drill big holes in wood but rarely in masonry
VALUE
Ryobi ONE+ 18V PCL206 Drill/Driver
Ryobi ONE+ PCL206 18V 1/2 in. drill/driver kit on white: drill with the 18V 1.5Ah ONE+ battery attached, next to the ONE+ charger

The Ryobi ONE+ PCL206 appears in more of our sources than any other budget drill. Reviewed named it its best value, Bob Vila's testers made it their best for home use, BestReviews called Ryobi its best budget brand, and both Bob Vila's under-$100 test and Outdoor Life's field test included it.

Best for:
  • First-time homeowners
  • Occasional jobs like hanging shelves and assembling furniture
  • Anyone starting a Ryobi ONE+ tool collection
  • Budget shoppers who want a battery and charger included
04

Specifications

Spec DeWalt 20V MAX XR DCD800 Drill/Driver Ryobi ONE+ 18V PCL206 Drill/Driver
Max Torque Not listed (UWO-rated) 515 in-lbs
Voltage 20V MAX 18V ONE+
Max Speed 2,000 rpm 1,750 rpm
Weight 3.2 lb (bare) 2.6 lb
Chuck 1/2 in. metal ratcheting 1/2 in. keyless ratcheting
Clutch Settings 15 24
Hammer Mode None None
Motor Brushless Brushed
Head Length 6.4 in Not listed
